HD1607

HD1607

Details

Description of the designHigh-dispersive mirror
TypeMirror
SubtypeHigh(negative)-dispersion mirror
Angle of Incidence in degrees5 °
Polarization regime (primary spectral range)p,s
Spectral categoryNIR
Spectral working range low end755 nm
Spectral working range high end805 nm
Central wavelength780 nm
Nominal GDD-1000 fs2
Minimum reflectance99.94 %
Maximum reflectance-
Minimum transmission-
