HD1501

Details
Description of the design | Dispersive mirror |
Type | Mirror |
Subtype | DM (dispersive mirror) |
Angle of Incidence in degrees | 5 ° |
Polarization regime (primary spectral range) | p |
Spectral category | IR |
Spectral working range low end | 2000 nm |
Spectral working range high end | 2200 nm |
Central wavelength | 2100 nm |
Nominal GDD | -1000 fs2 |
Minimum reflectance | 99.95 % |
Maximum reflectance | - |
Minimum transmission | - |
