CM1321_RC2
Details
| Description of the design | High-reflective mirror |
| Type | Mirror |
| Subtype | HR (high-reflection) mirror |
| Central wavelength | 805 nm |
| Spectral working range low end | 770 nm |
| Spectral working range high end | 840 nm |
| Maximum reflectance | - |
| Minimum reflectance | 99.95 % |
| Nominal GDD | 0 fs2 |
| Angle of Incidence in degrees | 0 ° |
| Polarization regime (primary spectral range) | p |
| Minimum transmission | - |
| Spectral category | IR |
