BS1202

BS1202

Details

Description of the designThin-film polarizer
TypeBeam splitter
SubtypeBS (Beam splitter)
Nominal GDD-fs2
First working range
Angle of Incidence in degrees45 °
Angle of Incidence in degrees (double-angle)-
Polarization regime (primary spectral range)p
Spectral categoryIR
Spectral working range low end1015 nm
Spectral working range high end1050 nm
Central wavelength1032 nm
Minimum reflectance0 %
Maximum reflectance1 %
Minimum transmission95 %
Second working range
Second spectral working range low end1015 nm
Second spectral working range high end1050 nm
Polarization regime (second working range)p
Minimum reflectance99 %
Minimum transmittance-
