PC61

PC61

Details

Description of the design Broad-band complementary pair
Type Mirror
Subtype BBDM (broad-band dispersive mirror)
Angle of Incidence in degrees 5 °
Polarization regime (primary spectral range) p
Spectral category IR
Spectral working range low end 1000 nm
Spectral working range high end 1750 nm
Central wavelength 1375 nm
Nominal GDD -150 fs2
Minimum reflectance 99 %
Maximum reflectance -
Minimum transmission -
